AMD Radeon Software has recently developed and launched Radeon RX 7900 XT it can be available from November 3rd, 2022. This card is powered by a 5 nm process. Moreover, it is helmed by Navi 31 graphics processor, with Navi 31 XT variant. It is also said that the card will support DirectX 12 Ultimate. All the embedded processors on Radeon RX 7900 XT ensure the ultimate performance of modern games and upcoming video games. The inclusion of DirectX 12 Ultimate further assists the connected system and video games to facilitate hardware-ray-tracing, variable-rate shading, and many more. Radeon RX 7900 XT happens to be a dual slot card that is capable of driving power from two 8-pin power connectors and also draws 300 W maximum power. The price of the AMD Radeon RX 7900 XT is 899 US Dollars.
The specifications of the Radeon RX 7900 XT is as follows
Graphics Processor
GPU Name
Navi 31
GPU Variant
Navi 31 XT
Architecture
RDNA 3.0
Foundry
TSMC
Package
MCM
Process Size
5 nm
Transistors
58,000 million
Density
188.3M / mm²
Full Size
495.5 mm²
Die Size
306 mm²
MCD Size
37.5 mm² x5
MCD Process
6 nm
Graphics Card
Release Date
Nov 3rd, 2022
Availability
Dec 13th, 2022
Generation
(RX 7000)
Predecessor
Navi II
Production
Active
Launch Price
899 USD
Bus Interface
PCIe 4.0 x16
Clock Speeds
Base Clock
1500 MHz
Shader Clock
2000 MHz
Game Clock
2000 MHz
Boost Clock
2400 MHz
Memory Clock
2500 MHz
20 Gbps effective
Memory
Memory Size
20 GB
Memory Type
GDDR6
Memory Bus
320 bit
Bandwidth
800.0 GB/s
Render Config
Shading Units
5376
TMUs
336
ROPs
192
Compute Units
84
RT Cores
84
L0 Cache
64 KB per WGP
L1 Cache
256 KB per Array
L2 Cache
6 MB
L3 Cache
80 MB
Theoretical Performance
Pixel Rate
460.8 GPixel/s
Texture Rate
806.4 GTexel/s
FP16 (half) performance
103.2 TFLOPS (2:1)
FP32 (float) performance
51.61 TFLOPS
FP64 (double) performance
3.226 TFLOPS (1:16)
Board Design
Slot Width
Dual-slot
Length
267 mm
10.5 inches
Width
135 mm
5.3 inches
Height
50 mm
2 inches
TDP
300 W
Suggested PSU
700 W
Outputs
1x HDMI 2.1a
2x DisplayPort 2.1
1x USB Type-C
Power Connectors
2x 8-pin
Part Number
Graphics Features
DirectX
12 Ultimate (12_2)
OpenGL
4.6
OpenCL
2.1
Vulkan
1.3
Shader Model
6.7
Navi 31 GPU Notes
| Architecture Codename: Navi
Codename: Plum Bonito Graphics/Compute: GFX11 (gfx1100) Display Core Next: 4.0 Video Core Next: 4.0
Per SIMD32: – 10 KB Scalar Register File
Per CU: – 16 KB Vector Data Cache – 64 KB Local Data Share (GCN-Mode)
Per WGP: – 16 KB Scalar Data Cache / K Cache – 32 KB Instruction Cache – 128 KB Local Data Share |
Conclusion
This set of specifications will help the video game to operate with utmost efficiency. The AMD Radeon RX 7900 XT will cost 899 US Dollars.
